K–10 SEcTIoN K Hangers & Fittings
Quality, Durability, Reliability

K SAMMY ScREWS

SAMMY ScREWS FoR Wood vERTIcAL MouNT

- Self threading in wood
- Rod size is 3/8”

PART# ModEL TYPE SIzE
1088200 GST-20 1/4" x 2"

1088300 GST-30 1/4" x 3"
1088380 GST-25-380 3/8" x 2-1/2"

SAMMY ScREWS FoR Wood HoRIzoNTAL MouNT

HANGERS & FITTINGS SAMMY ScREWS FoR Wood SWIvEL MouNT ModEL TYPE SIzE
- Self threading in wood
- Rod size is 3/8”

PART#
1/4" x 1"
1086302
SWG10
1089302
1/4" x 2"
SWG20
3/8" x 2-1/2"
SWG-25-380
1089380

- Use Driver 109914
- Allows rod to hang plumb, No need to bend rod
- Deflection from vertical = 17°
- Accommodates 3-1/2” by 12” pitch roof
- Self threading in wood
- Rod size is 3/8”

PART# ModEL TYPE SIzE
1088200S SH-GST 20 1/4" x 2"
1088300S SH-GST 30 1/4" x 3"
LynCar order desk: (800) 263-7011 • lyncar.com • 24 hr. order Fax: (800) 459-6227
