K–24 SEcTIoN K Hangers & Fittings
Quality, Durability, Reliability

K bRASS FLARE & coMPRESSIoN FITTINGS

FLARE - 46 PART# SIzE coMPRESSIoN PART# SIzE
SERIES 7-4642 1/4” x 1/8” - 62 SERIES 7-622 1/8”
3/16”
7-623
7-4644
1/4”
x FIP 7-4654 5/16” x 1/4” uNIoN 7-624 1/4”
couPLING 7-4662 3/8” x 1/8” 7-6242 1/4” x 1/8”
7-4666 3/8” 7-625 5/16”
7-4668 3/8” x 1/2” 7-6254 5/16” x 1/4”
7-4684 1/2” x 1/4” 7-626 3/8”
7-4686 1/2” x 3/8” 7-6264 3/8” x 1/4”
7-628
1/2”
7-4688 1/2” 7-6286 1/2” x 3/8”
7-46812 1/2” x 3/4” 7-6210 5/8”
7-46108 5/8” x 1/2” 7-62106 5/8” x 3/8”
7-461012 5/8” x 3/4” 7-62108 5/8” x 1/2”
7-461212 3/4” x 3/4” 7-6214 7/8”
FLARE - 48 PART# SIzE coMPRESSIoN PART# SIzE
SERIES 7-4842 1/4” x 1/8” - 66 SERIES x 7-6642 1/4” x 1/8”
7-6644
1/4”
x MIP 7-4844 1/4” FIP couPLING 7-6648 1/4” x 1/2”
1/4” x 3/8”
7-4846
couPLING 7-4848 1/4” x 1/2” 7-6654 5/16” x 1/4”
7-4854 5/16” x 1/4” 7-6662 3/8” x 1/8”
7-4856 5/16” x 3/8” 7-6664 3/8” x 1/4”
7-4864 3/8” x 1/4” 7-6666 3/8”
7-4866 3/8” 7-6668 3/8” x 1/2”
7-4868 3/8” x 1/2” 7-6684 1/2” x 1/4”
7-48612 3/8” x 3/4” 7-6686 1/2” x 3/8”
HANGERS & FITTINGS coMPRESSIoN 7-4888 1/2” x 1/2” coMPRESSIoN PART# SIzE
7-6688
7-4884
1/2” x 1/4”
1/2”
7-66108
5/8” x 1/2”
7-4886
1/2” x 3/8”
7-48108
5/8” x 1/2”
7-481012
5/8” x 3/4”
7-48812
1/2” x 3/4”
SIzE
PART#
- 61 SERIES
60 SERIES
3/16”
7-602
7-613
1/8”
7-603
SLEEvE
7-615
5/16”
7-604
1/4”
7-616
3/8”
7-605 3/16” SHoRT NuT 7-614 1/4”
5/16”
7-606 3/8” 7-618 1/2”
7-607 7/16” 7-6110 5/8”
7-608 1/2”
coMPRESSIoN PART# SIzE - Three piece unit: body, nut and sleeve.
- Straights and shapes are manufactured from CA360, CA345,
64 SERIES TEE 7-643 3/16” CA377.
7-644 1/4” - Compatible with copper, brass, aluminum and thermoplastic
7-645 5/16” tubing. (Thermoplastic tubing requires the use of a brass insert
for support.)
7-646 3/8” - Low pressure air, oil, water and gas up to a maximum pressure
7-648 1/2” of 400 psi.
7-6410 5/8” - Fair vibration resistance
- The long nut can be used for greater vibration application.
LynCar order desk: (800) 263-7011 • lyncar.com • 24 hr. order Fax: (800) 459-6227
